特点：

该机专为包装纸盒尺寸多批量小的厂家独立设计。2

成本低，占地面积小。适用于各种尺寸的盒子。该机是 种具有多功能的垂直型自动装盒机，更换规格改变模具时间短。2

304不锈钢外壳

进的PLC控制系统结合5.7彩色触摸屏控制面板，可以轻松地设置和改变包装参数。2

FEATURES:

2  It is specially design to pack small quantities multi size box.

2  With low cost and only require small area. It is suitable for various sizes of box. The machine is a vertical type with multiple function and require a short time to change mould.

2  304 stainless steel case

2  Advanced PLC Control System Combined with 5.7” Colorful Touch Screen Control Panel , can easily set and change the packing parameters.

选配功能：

 自动加说明书，热熔胶喷胶封盒，碳带日期批号打印

 OPTION :

l    Leaflet Inserting , Hot Glue, Hot Ribbon Date Code , Embossed date Code

1、把纸盒吸到星轮。

Push box into star wheel.

2、折叠纸盒下小舌。

Fold box lower small flap.

3、折下盖。

Press both lower big flaps.

4、插入下大舌

Flatten both big flaps.

5产品装入纸盒。

Product fall into box.

6折叠纸盒上小舌。

 Fold box upper small flap.

7折上盖。

Press both upper  big flaps.

8插入上大舌

 Flatten both big flaps.

9成型产品推出。

Product push out.

适应：制药行业，食品行业，化妆品行业，电子行业纸盒立式自动成型包装。

APPLICATION :

Round bottled medicine, food-stuff, cosmetic, etc. packing into square box.
